Herbal Extract Centrifugal Spray Dryer 80kg/h 95 Percent Powder Recovery

Chinese medicine extract and plant extract are the hardest feeds a spray dryer faces: high viscosity, high sugar content, strong hygroscopicity and a tendency to stick on a hot wall and scorch. The ZPG series herbal extract centrifugal spray dryer was designed around that problem. A three stage air purification train brings the inlet air to a clean room grade, a cooling wall keeps the tower shell below 80 °C so the deposit on the wall never carbonizes, and an air sweep device continuously wipes the inner surface, so the powder leaves the tower light in colour and fully soluble instead of brown and burnt.

Compared with a standard centrifugal spray dryer working on the same extract, this herbal extract centrifugal spray dryer recovers at least 95% of the powder instead of the 60% to 70% typical of an unstirred tower, and its throughput is about 3.5 times higher for the same tower diameter. Wet scrubbing instead of a dry bag filter removes the fines from the exhaust, so there is no dust emission at the stack and the plant meets local environmental limits without adding a second dedusting stage.

• 80 kg/h Evaporation Capacity: the ZPG-80 herbal extract centrifugal spray dryer processes 80 to 108 kg/h of liquid feed and delivers 14.8 to 22.4 kg/h of dry powder at 18% to 25% solid content.
• 95 Percent Two Stage Recovery: a primary cyclone plus a secondary dust collector, or a cyclone plus wet scrubber, holds powder recovery at 95% or above, which is decisive when the extract is expensive.
• Cooling Wall Below 80 °C: the cylinder and the cone top are fitted with a cooling jacket so the wall stays under 80 °C and sticky extract deposits dry without scorching or discolouring.
• Air Sweep Anti Sticking: a compressed air sweep device mounted inside the tower breaks the wall deposit continuously, which raises the collection rate and removes the manual hammering that damages the tower lining.
• 150-200 °C Inlet Flash Drying: the inlet air is held between 150 and 200 °C and the outlet between 80 and 100 °C by automatic controllers, so the droplet dries in seconds and the powder keeps 3% to 5% final moisture.
• Fast Open Cleaning: quick opening covers and a water wash ring allow a product change within one shift, which suits multi variety extract production under GMP documentation.

The herbal extract centrifugal spray dryer is used wherever a sticky, heat sensitive liquid must become a free flowing powder in one pass:

1. Traditional Chinese medicine extract, single herb concentrate and compound formula concentrate with high sugar or polysaccharide content.
2. Plant extract such as stevia, ginkgo, tea polyphenol and grape seed extract requiring colour retention.
3. Natural pigment and dye liquid that discolours above 90 °C.
4. Enzyme and probiotic fermentation broth where activity must survive the drying step.
5. Viscous food and nutraceutical concentrate such as honey, molasses and herbal syrup base.

Because the powder is produced in a single pass with no crushing and no sieving afterwards, the herbal extract centrifugal spray dryer keeps the process route short and protects the product from the contamination that a milling step would introduce.

Why does the powder no longer turn brown? Because two things are controlled: the cooling wall keeps the shell under 80 °C so wall deposits cannot carbonize, and the air sweep removes those deposits before they overheat. That is the main reason this herbal extract centrifugal spray dryer produces a light coloured powder.

How is 95% powder recovery achieved? Fines that leave the tower are captured by a primary cyclone and then either a secondary cyclone or a wet scrubber. The wet scrubber also dissolves the residual fines into water, so nothing leaves the stack and the recovered material can be returned to the feed tank.

What feed consistency is required? The ZPG-80 runs best at 18% to 25% solid content and a viscosity low enough to atomize. Thicker extract is usually pre diluted or pre concentrated to hit that window, and a pilot test on your material is recommended before ordering.

Can the same machine run several herbal formulas? Yes. The quick opening tower, the water wash ring and the recipe memory of the control system allow a product change within one shift, which is the normal pattern in a multi formula extract plant.

The herbal extract centrifugal spray dryer ships in sections: tower, cyclone, wet scrubber, air heater, fan and control cabinet, each in an export plywood case with a flange and bolt list. Air volume, temperature control accuracy, atomizer balance and electrical safety are verified before dispatch, and the documentation includes material certificates, an IQ OQ template and a cleaning validation guide. The 12 month warranty is supported by a spare kit covering the atomizer, nozzles, sweep air valves, filter elements and pump seals.
