Automatic Bin Blender Powder Mixer Machine 750kg Net Load 3-15rpm Multi Bin

A tablet line that runs five products in a week cannot afford to clean a fixed blender between every batch. The HZD-800A automatic bin blender solves this by never touching the product directly: the bin itself is the mixing chamber. The machine lifts the bin, clamps it, rotates it at 3 to 15 rpm and lowers it back onto its own frame, so a single automatic bin blender serves an entire fleet of bins and the product simply moves from granulation to blending to tableting in the same container.

That container-as-mixer principle is the reason the automatic bin blender fits GMP solid dosage plants so well. There is no transfer, no discharge chute, no dust release and no cross contamination between products, because each product stays in its own validated bin with its own label and batch record. With a 750 kg net load on the HZD-800A and a bin range from 300 to 2000 L, one machine covers pilot batches and full production batches without mechanical adjustment.

• 750 kg Net Load Per Bin: the HZD-800A handles a full production batch in one lift, and the same automatic bin blender also accepts smaller bins for pilot quantities, so no separate pilot machine is needed.
• Multi Bin Flexible Blending: one main machine plus several bins of different sizes satisfies multi product, multi batch production, which is exactly the profile of a contract manufacturer or a multi SKU tablet plant.
• 3 to 15 rpm Gentle Tumbling: the low rotation speed produces a soft cascading motion that blends a fragile granule or a coated pellet without attrition, and the blend reaches uniformity in 8 to 15 minutes.
• Automatic Lift and Lower: raising, clamping, blending and lowering are carried out from one control station, so a single operator can run several batches per shift without manual handling of a loaded bin.
• Zero Transfer Contamination: material never leaves the bin between process steps, so there is no dust escape, no product loss and no cleaning of a fixed vessel between products, which is the core GMP argument for a bin blender.
• Sealed Butterfly Discharge: the bin discharges through a butterfly valve straight into a tablet press, a capsule filler or a packaging line, keeping the product in a closed system from granulation to packaging.

The automatic bin blender is the standard total blending unit in a modern solid dosage plant, and it also fits any powder process where containers can replace fixed vessels:

1. Final blend before tableting or capsule filling, where the bin feeds the press directly.
2. Granulate homogenizing after fluid bed drying, in the same bin that collected the batch.
3. Multi product contract manufacturing, where each product keeps its own dedicated bin.
4. Chemical and food powder blending where dust containment and allergen control are critical.
5. Pilot and clinical trial batches, run in small bins on the same production machine.

Because blending happens inside the bin, the automatic bin blender also removes the manual lifting step: a loaded 750 kg bin is handled by the machine, not by an operator with a pallet truck, which reduces both labour cost and the risk of a dropped or mislabelled batch.

How many bins can one automatic bin blender serve? There is no fixed limit. The machine is matched to the largest bin and the control stores a recipe per bin size, so a plant typically runs six to twenty bins on one machine and schedules blending by bin availability.

Is 3 to 15 rpm fast enough to blend 750 kg? Yes. Tumbling blenders rely on bed exchange rather than on speed, so 8 to 15 minutes at 3 to 15 rpm brings a 750 kg batch to a coefficient of variation below 5%, and the low speed protects fragile granules.

Does the product really need no cleaning between batches? Between different products, no: each product uses its own bin, which is washed separately. The automatic bin blender itself only contacts the bin exterior, so cleaning is limited to the clamp and the drive, a matter of minutes.

Can the bin feed a tablet press directly? Yes. With a butterfly valve and a discharge station the bin can be placed on the press, so the blend goes from the automatic bin blender to the press without any intermediate container or manual handling.

The automatic bin blender ships in two sections, the lifting column and the rotation frame, each braced inside an export plywood case, with the control cabinet packed separately. Load testing with a weighted bin, interlock verification, a no load rotation test and a full electrical safety report are completed before shipment. The warranty covers 12 months on mechanical and electrical parts, and we supply clamp pads, drive brakes, seal kits and PLC backup files as a two year spare package, together with installation, operator training and validation documentation.
